The PL750D updates DeepCool non-modular PSUs with a 12V-2x6 cable and brings them into compliance with INTEL's ATX3.1 standard. These units are 80 PLUS Bronze-verified, come with a 120mm hydro-bearing fan, and will provide stable power for years to come.
| CATEGORY | SPECIFICATIONS |
| Type | ATX12V V3.1 |
| Product Dimensions | 150 × 140 × 86 mm (W × L × H) |
| Efficiency Certification | 80Plus Bronze / Cybenetics Silver / PPLP Silver / CQC II 级 |
| Fan Size | 120mm |
| Fan Bearing | HYB (Hydro Bearing) |
| Topology | Active PFC + DC to DC |
| Capacitors | Chinese Electrolytic Capacitors |
| Power Good Signal | 100–150ms |
| Hold-Up Time | ≥16ms |
| Efficiency | ≥85% under typical load (50% loading) |
| Protection | OPP / OVP / SCP / OTP / OCP / UVP / SIP / NLO |
| Operating Temperature | 0 – 40℃ |
| Regulatory Certifications | CE / FCC / CCC / RCM / EAC / BIS / CAN ICES-003(B) / NMB-003(B) / TUV-RH |
| ErP Regulation | ErP 2014 |
| Environmental Protection | WEEE / 中国 RoHS / Triman / P65 |
| MTBF | 100,000 Hours |
