* Supports Intel® Core™ 14th/ 13th /12th processors * Dual Channel Non-ECC Unbuffered DDR4, 2 DIMMs * GbE LAN with Bandwidth Management * NVMe PCIe 3.0 x4 M.2 * High Quality Audio Capacitors and Audio Noise Guard * Smart Fan 6 Features Multiple Temperature Sensors , Hybrid Fan Headers with FAN STOP * GIGABYTE APP Center, Simple and Easy Use * Anti-Sulfur Resistors Design | ITEM | SPECIFICATION | |--------------------------|------------------------------------------------------------------------------| | CPU Support | LGA1700 socket: 14th / 13th / 12th Gen Intel® Core™, Pentium® Gold, Celeron® | | Chipset | Intel® H610 Express Chipset | | Form Factor | Micro ATX Form Factor; 22.6cm x 18.5cm | | Memory | 2 x DDR4 DIMM sockets (up to 64 GB)
DDR4 3200/3000/2933/2666/2400/2133 MT/s | | Memory Architecture | Dual channel | | ECC Support | ECC Un-buffered DIMM 1Rx8/2Rx8 (non-ECC mode)
Non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 | | XMP Support | Yes | | Onboard Graphics | Integrated Intel® UHD Graphics
1 x HDMI 2.1 (4096x2160@60Hz)
HDCP 2.3 | | Audio | Realtek® Audio CODEC
2/4/5.1/7.1-channel HD Audio | | LAN | Realtek® GbE LAN chip (1 Gbps/100 Mbps) | | Expansion Slots | 1 x PCIe 4.0 x16 (CPU)
1 x PCIe 3.0 x1 (Chipset) | | Storage Interface | 1 x M.2 (PCIe 3.0 x4/x2, type 2280/2260)
2 x SATA 6Gb/s connectors | | USB Ports (Rear) | 2 x USB 3.2 Gen 1
4 x USB 2.0/1.1 | | USB Ports (Internal) | 1 x USB 3.2 Gen 1 header
1 x USB 2.0 header | | Internal Connectors | 24-pin ATX main power
8-pin ATX 12V
CPU & System fan headers
TPM header
Clear CMOS jumper | | Back Panel I/O | 1 x HDMI
2 x USB 3.2 Gen 1
4 x USB 2.0
1 x RJ-45
3 x Audio jacks | | H/W Monitoring | Voltage, temperature, fan speed, water cooling flow, fan fail warning | | Fan Speed Control | Yes (dependent on cooler) | | BIOS | 128 Mbit AMI UEFI BIOS | | BIOS Features | Q-Flash, PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 | | Unique Features | APP Center, @BIOS, EasyTune, Smart Backup, System Info Viewer | | Bundled Software | Norton® Internet Security (OEM), LAN Bandwidth Management | | OS Support | Windows 11 64-bit, Windows 10 64-bit |
